ALI Certified 99,000 lb Mobile Column Lift for Heavy-Duty Truck & Fleet Service
The Atlas Maxima® ML-6045BC Mobile Column Lift System is designed for professional repair facilities that service heavy-duty trucks, buses, motorhomes, and commercial fleet vehicles. Featuring six ALI Certified mobile lifting columns, this system delivers a combined lifting capacity of 99,000 pounds, with each column capable of lifting 16,500 pounds. Its portable design allows technicians to position the lift wherever it's needed, maximizing shop space and providing the flexibility to service vehicles indoors or on level concrete outdoors.
Each column is powered by a 2.2 kW 24V DC motor with dual rechargeable batteries, providing cordless operation and dependable lifting performance throughout the workday. An advanced electronic synchronization system keeps all six columns lifting evenly, while hydraulic flow control and mechanical safety locks provide redundant protection during operation. Every column features an LCD display that shows real-time lifting height and an emergency stop button for added operator safety and control.
Designed to accommodate a wide range of commercial vehicles, the ML-6045BC features adjustable wheel forks that fit tire diameters from 19 to 44 inches. Integrated hydraulic pallet jack systems make repositioning the columns quick and effortless, allowing your shop to adapt to changing workloads while maintaining maximum productivity.
Atlas ML-6045BC Specifications
Specification
Details
Lifting Capacity (Per Column)
16,500 lbs
System Configuration
6 Columns
Total Lifting Capacity
99,000 lbs
Maximum Lifting Height
67"
Overall Height
145"
Resting Height
88.5"
Overall Width
43.5"
Overall Length
55.5"
Column Width
13.25"
Tire Diameter Range
19" – 44"
Motor
2.2 kW, 24V DC with Dual Batteries per Column
Battery Charger Power
110V
Concrete Requirement
Minimum 4" thick, 3,500 PSI
Warranty
2-Year Limited
Shipping Information
Shipping Weight (Per Column): 1,600 lbs
Shipping Weight (Six Columns):9,600 lbs
Shipping Dimensions (Per Column): 49" L × 47" W × 89" H
Key Features
ALI Certified to meet industry-recognized safety and performance standards
Six-column mobile lift system with a combined 99,000 lb lifting capacity
16,500 lb lifting capacity per individual column
Portable design allows lifting virtually anywhere on level concrete
Simultaneous synchronized lifting across all six columns
Advanced electronic synchronization system maintains level lifting
LCD display on every column provides real-time lifting height information
Dual safety protection with hydraulic flow control and mechanical locking systems
Emergency stop button located on every column
Adjustable wheel forks accommodate tire diameters from 19" to 44"
Dual rechargeable battery system enables cordless operation
Integrated hydraulic pallet jack system for easy positioning
Includes six 32-foot interconnecting cables
Ideal for servicing heavy-duty trucks, buses, RVs, municipal fleets, emergency vehicles, and commercial equipment
Atlas 2-Year Limited Warranty
The Atlas Maxima® ML-6045BC is backed by a 2-Year Limited Warranty, providing dependable coverage and peace of mind for professional heavy-duty lifting applications.
