Description
The Katool KT-TV910 Hydraulic Truck Tire Changer is a heavy-duty electro-hydraulic system designed to meet the demanding needs of trucks, buses, tractors, and earth-moving vehicles. Built for superior performance and versatility, it accommodates wheels from 14 to 42 inches in diameter, providing exceptional service flexibility across a range of heavy vehicles.
The machine’s multifunctional control system enables safe, precise operation from any position, while its powerful beak and disk mechanism ensures efficient bead breaking and tire handling—even on sensitive rims. For operator comfort and safety, the ergonomically positioned foot pedals and conveniently located helper controls streamline workflow and minimize operator fatigue. Additionally, low-voltage electrical components enhance operational safety, making the KT-TV910 a dependable and secure choice for professional tire service environments.
Key Features
-
Heavy-Duty Electro-Hydraulic System: Engineered for trucks, buses, tractors, and earth-moving vehicles.
-
Wide Clamping Range: Handles wheels from 14" to 42" in diameter for maximum versatility.
-
Multifunctional Controls: Allows safe operation from multiple positions for better convenience and precision.
-
Powerful Beak & Disk Design: Provides strong, accurate bead handling while protecting delicate rims.
-
Ergonomic Operation: Foot pedals and helper controls are intuitively placed for efficiency and ease of use.
-
Enhanced Safety: Equipped with low-voltage electrical components to ensure complete operator protection.
Specifications
| Specification | Value |
|---|---|
| Outer Rim Range | 14" – 42" |
| Max Wheel Diameter | 63" (1600 mm) |
| Max Wheel Width | 31" (780 mm) |
| Working Pressure | ≤130 bar |
| Power Supply | 220V / 1PH / 60Hz |
| Hydraulic Motor Power | 3.0 kW (4.0 HP) |
| Max Oil Flow (Hydraulic Motor) | 315 |
| Max Tire Weight | 3,306 lbs (1,500 kg) |
| Net Weight | 1,256 lbs (570 kg) |
| Shipping Weight | 1,388 lbs (630 kg) |
| Shipping Dimensions | 51" x 43" x 72" (1300 x 1100 x 1830 mm) |
| Noise Level | < 70 dB(A) |
Warranty & Support
Katool provides a 1-year limited warranty covering all parts and manufacturing defects free of charge. A 2-year extended warranty is also available for Katool and M&E automotive equipment.
Warranty Coverage Includes:
-
Hydraulic cylinders, power units, motors, displays, and electronic components
-
Vehicle lifts include an additional 3-year structural warranty
Warranty Conditions:
-
-
Claims must be submitted within the warranty period.
-
Warranty is non-transferable and requires proof of purchase or the original order number from an authorized vendor.
-
Replacement parts and shipping are covered at no cost.
-
All claims must be approved by Katool’s warranty/service department.
-
Photos or videos of the defect may be required for verification.
-
Do not disassemble equipment before receiving approval.
-
Items outside warranty coverage will require the buyer to cover replacement and shipping costs.
-
Labor costs are not included under the warranty.
-
