Description

Triumph NTO-16 16,000 lb 2 Post Lift

The Triumph NTO-16 16,000 lb Two Post Lift is designed for service environments that require higher lifting capacity for larger vehicles. Built to accommodate heavy-duty applications, this lift provides the strength and stability needed to service trucks, commercial vehicles, and other larger automobiles.

With a 16,000 lb lifting capacity and a maximum lifting height of 72 inches, the NTO-16 provides technicians with comfortable access to the underside of vehicles for inspections, maintenance, and repairs. The lift features direct-drive hydraulic cylinders designed to provide smooth and consistent lifting performance during operation.

Its overhead design routes cables and hydraulic lines above the workspace, helping keep the shop floor clear and organized. A single-point lock release system simplifies operation, while the electric safety cutoff adds an additional safety feature during lifting.

The NTO-16 also offers a 102-inch drive-through width and 116-inch spacing between posts, allowing it to accommodate a wide range of larger vehicles. Powered by a 3 HP motor, the lift raises vehicles in approximately 40 seconds, helping maintain efficient workflow in busy service environments.

The NTO-16 replaces the earlier NTO-15 model with updates to the lift structure and components, providing improved durability and performance.

Triumph NTO-16 Specifications

Lifting Capacity: 16,000 lbs
Overall Height: 165"
Overall Width: 142"
Maximum Lifting Height: 72"
Distance Between Posts: 116"
Drive-Thru Width: 102"
Lowered Height: 7"
Base Plate Size: 20" × 20"
Lift Time: 40 seconds
Power Requirement: 220V
Motor: 3 HP
Concrete Requirement: 6" slab, 3,000 PSI
Style: Overhead
Lock Release: Single-point
Electric Safety Cutoff: Yes
Pallet Dimensions: 144" × 36" × 48"

Triumph NTO-16 16,000 lb 2 Post Lift Features

  • 16,000 lb lifting capacity designed for servicing larger vehicles

  • Direct-drive cylinders for smooth and reliable lifting performance

  • Single-point lock release simplifies lift operation

  • Electric override with automatic safety shut-off

  • 40-second lifting time for efficient service work

  • Overhead design keeps cables and hoses routed above the workspace

  • Includes mounting hardware and truck adapters

  • Certification: CE Certified, manufactured in ISO9001-certified facilities

Warranty

1-year parts warranty
5-year structural warranty

NTO-16 Manual



Warehouse Pickup Locations (No Shipping Fee):

  • Columbus, OH

  • Fort Worth, TX

  • North Las Vegas, NV

*A $200 additional freight surcharge applies for deliveries to Northern California, South Dakota, North Dakota, Montana, and Wyoming. If applicable, a separate payment link will be sent after your order to complete the freight charge.


Triumph NTO-16 Diagram View
